Integrated vision system for all processes of solar cell material and solar module production lines. Solar Inspection System
Overview
As the importance of inspection systems in solar production lines increases, efficient yield management and increased stability can be achieved by establishing an integrated vision system.
Features
-
Combines rule-based inspection and AI vision inspection to build a stable inspection solution (T-AIS applied).
- Rule-Based Inspection : Applied to process inspections such as dimensional measurement, gap inspection, and label attachment after solar module assembly.
- AI Inspection : Applies AI inspection through deep learning on various atypical defects (raw material appearance, assembly appearance, process inspection, solar panel EL inspection, etc.) using collected data (MOAI 4.0 applied). - Comprises over 30 vision inspections from raw material inspection to finished product quality and repair inspection, using a platform vision program.
-
Enhances process efficiency through VISION ALIGN.
- Applied to cell cutting, assembly, and welding processes. - Enables defect aggregation and type analysis for each process through the vision program.
- Detects fine defects of various types using high-resolution line scan cameras.
Inspection Composition
Dimension Measurement
| Inspection items | Outer size, dimensions, gap |
|---|---|
| Process | Cell supply, assembly, welding, AOI |
Raw Material Inspection
| Inspection items | Direction, crack, chip, discoloration, print |
|---|---|
| Process | Cell supply, assembly |
Process Inspection
| Inspection items | Wire cutting, welding condition, coating condition, alignment, process condition |
|---|---|
| Process | Gap, cutting, welding, assembly, coating |
Align
| Inspection items | 2POINT, 4POINT |
|---|---|
| Process | Cell supply, sheet assembly, material alignment, repair, bending |
Appearance Inspection
| Inspection items | Crack, chip, dust, wire, stain, bubble, delamination |
|---|---|
| Process | Cell supply, repair, AOI |
Panel EL Inspection
| Inspection items | CRACK, DARK CELL, MISS SOLDER |
|---|---|
| Process | Material, module EL inspection |
Introduction Effects
- Improved defect rates
- Defect analysis and process improvement
- Reduction in inspection personnel
Application Examples
- Company H : Introduction of vision system to domestic/overseas solar module production lines
Application Field
- Solar cell line process inspection, AOI, ALIGN
- Solar module assembly line process inspection, AOI, ALIGN
- Solar module EL inspection
